OV-350 CWDM 18 Channel

Overview

The OV-350 CWDM Channel Analyzer is a field-portable tool designed for accurate testing of CWDM networks. It features solid-state optics with no moving parts, ensuring durability in field environments. The unit provides rapid scan updates in less than 0.5 seconds, allowing for real-time monitoring of channel performance. It supports a wavelength range of 1271-1611nm for the 18-channel configuration, providing comprehensive coverage for CWDM infrastructure validation.

Key Features

• Fast Real-Time Analysis: Updates in under 0.5 seconds, allowing technicians to identify fluctuations or signal instability instantly.
• Solid-State Optics: Eliminates internal moving parts, which increases device longevity and resistance to mechanical shock in the field.
• Integrated Data Storage: Saves up to 1,000 individual test results, reducing the need for manual logging during high-volume testing sessions.
• User-Defined Thresholds: Allows operators to set custom pass/fail limits to ensure compliance with specific network design requirements.
• Visual Fault Locator (VFL): Includes an on-board 650nm laser, enabling the identification of fiber breaks or sharp bends without requiring additional equipment.
• Video Inspection Compatibility: Supports integration with the optional VIS-300 video probe to perform IEC61300-3-35 compliant fiber end-face inspection.
• USB Connectivity: Includes a dedicated PC port and software for efficient data transfer and the generation of professional test reports.

Technical Specifications

OV350CW18 PDF spec sheet 1
