Overview
The Quest Wall Mount Enclosure is a professional-grade solution designed for secure, organized, and accessible network equipment management. This 16RU enclosure features a robust, swing-out design that allows technicians to easily access the rear of installed components, significantly simplifying installation and maintenance in space-constrained data closets or telecommunication environments.
Constructed with durability and functionality in mind, the enclosure includes a reversible locking front door for flexible installation options and vented side panels to promote passive airflow. To maintain optimal operating temperatures for sensitive networking hardware, the unit arrives with pre-installed 110VAC cooling fans, ensuring reliable performance in busy enterprise environments.
Key Features
-
Swing-Out Design
Allows the enclosure to hinge open for convenient access to the rear of equipment, reducing time spent on maintenance. -
16RU Capacity
Provides sufficient vertical mounting space for standard 19-inch rack-mount equipment. -
Integrated Cooling Fans
Includes pre-installed 110VAC 80 CFM fans to manage heat levels and extend equipment lifespan. -
Reversible Front Door
Locking front door can be configured to open from the left or right side, adapting to specific room layouts. -
Adjustable Mounting Rails
Equipped with adjustable cage nut rails for precise depth configuration during installation. -
Marked RU Index
Rails are clearly labeled with RU space indicators for efficient equipment placement and organization. -
Vented Side Panels
Built-in ventilation improves air circulation, preventing overheating in enclosed wall-mount configurations.
Applications
- Telecommunications closets
- Data centers
- Network equipment rooms
- Security and surveillance recording stations
Package Contents
- 16RU Wall Mount Enclosure
- Cooling Fans (Pre-installed)
- Adjustable Cage Nut Rails
- Cage Nuts with #12-24 mounting screws
Technical Specifications
| Specification | Value |
|---|---|
| Model | WM30191602 |
| Rack Units | 16RU |
| Mounting Format | 19-inch |
| Door Style | Reversible, Locking |
| Cooling | Pre-installed 110VAC 80 CFM Fans |
| Construction | Vented side panels, hinged swing-out design |
| Mounting Hardware | #12-24 mounting screws, cage nuts |
Frequently Asked Questions
Is the front door reversible?
Yes, the front locking door is designed to be reversible for either left or right-side opening.
Does this enclosure come fully assembled?
Yes, the enclosure ships fully assembled and ready for installation.
Are the fans included?
Yes, the unit includes pre-installed 110VAC 80 CFM cooling fans.
What is the rack size?
This enclosure is designed for 19-inch standard rack-mount equipment.
Is the mounting rail depth adjustable?
Yes, the enclosure features adjustable cage nut rails for depth configuration.
