Signamax 24-Port Category 6 MDX-Series Patch Panel

Overview

The Signamax 24-Port Category 6 MDX-Series patch panel is a high-density, 1 rack-mount unit (RMU) solution designed to support high-performance networking environments. Engineered to exceed ANSI/TIA-568-C.2 performance specifications, this panel provides reliable bandwidth capabilities beyond 250 MHz, making it suitable for modern enterprise data center and telecommunications applications.

Constructed for durability, the panel features a fully enclosed modular design that protects the printed circuitry during termination. The system incorporates user-friendly features, including enhanced labeling options and integrated cable management for effective strain relief and organized cable routing, ensuring long-term connection integrity.

Key Features

• High-Density Design
  Features a 24-port configuration in a 1 RMU footprint to maximize rack space efficiency.
• Certified Performance
  Exceeds ANSI/TIA-568-C.2 component and link specifications to ensure reliable data transmission.
• Modular Architecture
  Fully enclosed, 6-port modular design protects circuitry and provides flexible deployment.
• Enhanced Connection Integrity
  Specialized RJ-45 contact design maintains stable, high-integrity connections under heavy use.
• Integrated Cable Management
  Built-in features allow for organized routing and necessary strain relief for incoming cabling.
• Simplified Termination
  Rear termination uses a 4-pair inline 110-type connector to reduce installation time and labor.
• Broad Compatibility
  Supports both T568A and T568B wiring schemes for seamless integration into existing networks.
• Durability
  Rated for a minimum of 750 plug insertions to support long-term network changes.

Applications

• Enterprise Data Centers
• Telecommunications Closets
• Local Area Networks (LAN)
• Voice and Data Integration

Technical Specifications
