Overview
The Signamax C-100 Series switch is an unmanaged, high-density network solution designed to provide reliable connectivity for enterprise and small business environments. This model features 16 Gigabit ports with Power over Ethernet (PoE+) capabilities, enabling the direct powering of network devices such as IP cameras, wireless access points, and VoIP phones through the Ethernet cable.
Equipped with 2 additional Gigabit SFP uplink ports, this switch offers flexible fiber connectivity options for long-distance network expansion or backbone connections. Built with a rugged metal housing, it is designed for demanding environments and includes integrated rack-mounting brackets to simplify installation in standard 19-inch equipment racks.
Key Features
-
PoE+ Support
Delivers up to 235W of total power budget, supporting power-hungry devices on all 16 ports. -
Gigabit SFP Uplinks
Includes 2 SFP ports to enable high-speed fiber backbone connections. -
Plug-and-Play Operation
Zero-touch configuration simplifies network deployment and reduces setup time. -
High Power Capacity
Features a 250W internal power supply to ensure consistent device operation. -
Rugged Construction
Durable metal chassis provides protection against environmental hazards and EMI. -
Rack-Ready
Ships with integrated mounting hardware for quick installation into standard server racks.
Applications
- Enterprise and small business network expansion
- IP security and surveillance camera systems
- Wireless access point powering and data backhaul
- VoIP telephony deployments
- Fiber-to-the-desk or backbone network extensions
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | Signamax |
| Model | C-100 (SC10050) |
| Total Ports | 18 |
| RJ45 Ports | 16 x 10/100/1000 Base-T/TX |
| SFP Ports | 2 x 1000/GbE SFP |
| PoE Budget | 235W |
| Internal Power Supply | 250W |
| Enclosure Material | Metal |
| Form Factor | Rack Mount (Includes Brackets) |
Frequently Asked Questions
Is this an unmanaged switch?
Yes, the C-100 is an unmanaged switch requiring zero configuration for installation.
Does it support PoE+ on all ports?
Yes, this model supports PoE+ across all 16 RJ45 ports.
Can I install this in a standard server rack?
Yes, it includes integrated mounting brackets specifically for rack installation.
What is the purpose of the SFP ports?
The 2 SFP ports are used for fiber optic uplinks to connect to other switches or high-speed network backbones.
Does it come with an internal power supply?
Yes, it features a 250W internal power supply.
