Fibercore Single Mode Fiber for 633nm and 688nm, 4.3/125µm Core/Cladding, 245µm Coating (per meter)
Roll over image to zoom in Click on image to zoom
Fibercore Single Mode Fiber for 633nm and 688nm, 4.3/125µm Core/Cladding, 245µm Coating (per meter)

Fibercore Single Mode Fiber for 633nm and 688nm, 4.3/125µm Core/Cladding, 245µm Coating (per meter)

FibercoreSKU: SM600
Price:
$ 5.95
Silicon Valley Based
Expert Support Since 2001
Fast CA or NY Shipping

FIBERCORE SM600 Single Mode Fiber for 633nm and 688nm. This fiber has 4.3µm core, 125µm cladding and 245µm coating. With single mode transmission characteristics well matched to HeNe laser at 633nm, Diode Laser at 680nm.

  • Singlemode transmission at all common Visible and NIR source wavelengths
  • 125µm glass diameter enables the use of standard ferrules, vgrooves and connectors
  • Typical 0.11 0.13 NA gives good resistance to bend induced loss without creating an unmanageably small mode.

FIBERCORE Single Mode Fibers Spec Sheet: SMF600 Spec Sheet
