Sumitomo LYNX2-MPO 12 Fiber Multimode OM3 Splice-On Connector (Male)

Overview

The Sumitomo LYNX2-MPO is a field-installable, fusion splice-on connector designed for customized, on-site optical fiber terminations. By utilizing advanced fusion technology, it provides high-density connectivity while allowing technicians to create permanent, precise-length terminations directly in the field.

Engineered for versatility, this connector is compatible with both optical ribbon fiber and 12-count loose tube round cord. It is an ideal solution for data centers, enterprise networks, FTTx deployments, and outside plant applications where customized cable lengths are required to eliminate excess slack or logistical delays associated with pre-terminated assemblies.

Key Features

• Field-Installable Design
  Enables rapid on-site terminations, eliminating the need for pre-engineered cable lengths.
• Fusion Splice Reliability
  Uses fusion splicing for a permanent, low-loss connection that maintains signal integrity.
• High-Density 12-Fiber MPO
  Supports 12-fiber connectivity to meet the high-density demands of modern data center infrastructure.
• Multimode OM3 Performance
  Optimized for OM3 multimode fiber environments.
• Male Configuration
  Features integrated guide pins for precise MPO alignment.
• MTP Compatibility
  Designed to be compatible with industry-standard MTP systems.
• Customizable Polarity
  Allows for field-manageable polarity to suit specific network topology requirements.
• Color-Coded Housing
  Simplifies identification and organization in high-density rack environments.

Applications

• Data Centers
• Enterprise Networks
• FTTx Network Infrastructure
• Outside Plant (OSP)
• Central Office Upgrades
• OEM Equipment Termination

Technical Specifications

Frequently Asked Questions

What does the 'Male' designation mean for this MPO connector?
The male designation indicates that the connector is equipped with guide pins necessary for aligning with female MPO connectors or adapters.

Is this connector compatible with loose tube cable?
Yes, the LYNX2-MPO is compatible with 12ct loose tube round cord as well as ribbon fiber.

Can I use this for high-density data center applications?
Yes, it is specifically designed to provide high-density fiber connectivity for data centers and enterprise networks.

Does this connector require epoxy?
No, it utilizes fusion splice technology for a permanent, field-installable connection without the need for traditional adhesives.

Is this connector MTP compatible?
Yes, the design is MTP compatible.
