T-BPD254-FS - Polka Dot Beamsplitter, Ø1", UV Fused Silica
T-BPD254-FS - Polka Dot Beamsplitter, Ø1", UV Fused Silica
Specifications | |
---|---|
Available Sizes | Ø1", Ø2", or 1" Square |
Beamsplitting Ratio | 50% ± 5% |
Minimum Beam Diameter for 50/50 Split |
2 mm |
Material | UV Fused Silica |
Wavelength Range | 250 nm - 2.0 µm |
Coating Pattern | Square-Coated Apertures 0.0040" (100 µm) Sides, 0.0022" (56 µm) Spacing |
Clear Aperture | >90% Diameter (Round Optics) >90% Length and Height (Square Optics) |
Thickness | 1.5 mm (Nominal) |
Dimensional Tolerance | +0.0 / -0.5 mm |
Angle of Incidence | 0 to 45° |
