T-BS035 - 10:90 (R:T) Non-Polarizing Beamsplitter Cube, 700 - 1100 nm, 5 mm
T-BS035 - 10:90 (R:T) Non-Polarizing Beamsplitter Cube, 700 - 1100 nm, 5 mm
| Item # | T-BS035 | |
|---|---|---|
| Cube Side Length | 5 mm | |
| Clear Aperture | >3.5 x 3.5 mm | |
| Transmitted Wavefront Error | <λ/4 | |
| Transmitted Beam Deviation | 0° ± 5 arcmin | |
|
Overall Performance |
Tabs = 87 ± 10%, Rabs = 7 +10/-7%, Tabs + Rabs > 85%, |Ts - Tp| < 10%, and |Rs - Rp| < 10% |
- Broadband AR-Coated Faces for 700 - 1100 nm
- Broadband Beamsplitter Coating on Internal Diagonal Surface
- 10:90, 30:70, 50:50, 70:30, or 90:10 (R:T) Split Ratio
- Sizes from 5 mm to 2" (See Below for Details)
- N-BK7 Substrate
- Size 5 mm Cube
| Item # | T-BS035 | |
|---|---|---|
| Cube Side Length | 5 mm | |
| Clear Aperture | >3.5 x 3.5 mm | |
| Transmitted Wavefront Error | <λ/4 | |
| Transmitted Beam Deviation | 0° ± 5 arcmin | |
| Overall Performance | Tabs = 87 ± 10%, Rabs = 7 +10/-7%, Tabs + Rabs > 85%, |Ts - Tp| < 10%, and |Rs - Rp| < 10% |
