T-YB1200-6/125DC - Ytterbium-Doped Single Mode Double-Clad Fiber, 7 µm MFD, Unit Pricing Per Meter

Fosco Connect Part No.: T-YB1200-6-125DC

  • $ 95.00 or



T-YB1200-6-125DC - Ytterbium-Doped Single Mode Double-Clad Fiber, 7 µm MFD, Unit Pricing Per Meter

Features

  • Ytterbium-Doped Silica Fiber for ~1000 nm to 1100 nm Fiber Lasers and Amplifiers
  • Single Mode and Large-Mode-Area Fibers Available
  • Core- and Cladding-Pumped Designs for 1 mW to >100 W Output Power
  • Matched Passive Fiber Also Sold Below
  • Industry-Standard Active Fiber Geometries with Ø125, Ø250, or Ø400 µm Cladding
  • Cladding-Pumped Design
  • Single Mode (SM) or Large-Mode-Area (LMA) Operation
  • High Pump Absorption with Low Photodarkening
  • High Slope Efficiency (75 - 84%)

Applications

  • High Average Power Pulsed Amplifiers
  • Medium and High-Power Pulsed and CW Lasers
  • Materials Processing
  • LIDAR
  • Rangefinding
  • Telecom-like Geometry for Compatibility With Standard Components Such as Gratings and Combiners
  • Cladding Geometry Octagonal
  • Absorption @ 920 nm 0.55 ± 0.1 dB/m
  • Core Diameter 7.0 ± 0.5 µm MFD
  • Cladding Diameter 125 ± 2 µm
  • Coating (Second Cladding) Diameter 245 ± 15 µm
  • Core NA 0.12
  • Core Index  We regret that we cannot provide this proprietary information
  • Cladding Index We regret that we cannot provide this proprietary information.
Item # Type Absorption
@ 920 nm
Pump
Type
Core
Diameter
Cladding
Diameter
T-YB1200-4/125 SM 280 ± 50 dB/m Core 4.4 ± 0.8 μm MFD 125 ± 2 μm
T-YB1200-6/125DC 0.55 ± 0.1 dB/m Cladding 7.0 ± 0.5 μm MFD
T-YB1200-10/125DC LMA 1.7 ± 0.3 dB/m 10.0 ± 1.0 μm
T-YB1200-20/400DC 0.55 ± 0.05 dB/m 20.0 ± 1.5 μm 400 ± 10 μm
T-YB1200-25/250DC 2.3 ± 0.3 dB/m 25.0 ± 1.5 μm 250 ± 5 μm
T-YB2000-10/125DC 2.0 ± 0.4 dB/m 10 ± 1.0 μm 125 ± 2 μm
