TH-CIR1550PM - PM Fiber Optic Circulator, 1520 - 1580 nm, No Connectors
Product Drawing
Center Wavelength 1064 nm
Polarization-Maintaining Fiber With No Connectors, FC/PC Connectors, or FC/APC Connectors
Damage Threshold of 300 mW (CIR1064PM) or 3 W (OC-L-1064)
Fast Axis Blocking
Wavelength Range 1520 - 1580 nm
Insertion Loss ≤0.9 dB
Isolationb ≥40 dB
Directivity (1-3) ≥50 dB
Polarization Extinction Ratio ≥22 dB
Return Loss ≥50 dB
Damage Threshold 300 mW
Package Dimensions Ø5.5 mm x 35 mm
Fiber SM15-PS-U25D
Length 1.0 +0.075/-0.0 m
Operating Temperature -5 to 70 °C
Storage Temperature -40 to 85 °C
Operating Relative Humidity 20% - 80%
Storage Relative Humidity 20% - 80%
