TH-DXM12DF - Multimode Ultrafast Detector with Current Monitor, 700 - 870 nm, DC - 12 GHz, FC/PC
TH-DXM12DF - Multimode Ultrafast Detector with Current Monitor, 700 - 870 nm, DC - 12 GHz, FC/PC
Fiber Type Ø50 µm MM OM4
Bandwidth DC - 12 GHz (at 780 nm)
Wavelength Range 700 - 870 nm
Responsivity 0.55 A/W
Conversion Gain 14 V/W
Optical Return Loss -18 dB
Noise-Equivalent Power (NEP) 47 pW/√Hz
Current Monitor Output 200 mV/mA
