TH-PAF2-A4C - Achromatic FiberPort, FC/PC & FC/APC, f = 4.0 mm, 1050 - 1620 nm, Ø0.76 mm Waist

Fosco Connect Part No.: THPAF2-A4C

TH-PAF2-A4C - Achromatic FiberPort, FC/PC & FC/APC, f = 4.0 mm, 1050 - 1620 nm, Ø0.76 mm Waist

EFL 4.0 mm

Input MFD 10.4 µm

Output 1/e²Waist Diameter 0.76 mm

Max Waist Distance 150 mm

Divergence 2.600 mrad

Lens Characteristics

Clear Aperture 1.8 mm
NA 0.22
Wavelength range of the antireflection coating 1050 - 1620 nm
The length from the tip of the connector bulkhead to the face of the FiberPort flange 0.70" (17.7 mm)
