THL-FPS301 - Fiber Preparation Station with Stripper and Cleaner for Ø80 µm to Ø400 µm Cladding
- Accepts Fiber with Cladding Diameters from 80 to 400 µm
- Strip Single or Dual Acrylate Coatings up to Ø600 µm
- Stripping and Cleaning Station
- Thermo-Mechanical Stripping
- Ultrasonic Cleaning Bath
- Includes Fiber Holding Blocks
- Includes Handset Controller
- Fiber Holder Inserts and TMS Blade Inserts Available Separately Below (Required for Operation)
| THL-FPS301 Specifications | |
|---|---|
| Accepted Fiber Buffer Diameters | Up to 600 µm |
| Accepted Fiber Cladding Diameters | 80 to 400 µma |
| Accepted Fiber Types | SM, PM, MM, Specialty Fibers Including Photonic Crystal Fiber (PCF) and Non-Circular Fiber, and Capillary Tubes |
| Thermo-Mechanical Stripper | |
| Accepted Coating Materials | Single or Dual Acrylate |
| Maximum Stripping Temperature | ~130 °F (54 °C) |
| Ultrasonic Cleaner | |
| Accepted Cleaning Solvents | Acetone or Isopropyl Alcohol |
| Cleaning Times | 1 to 120 s |
| General | |
| Operating Temperature | 0 to 40 °C (Non-Condensing) |
| Storage Temperature | -20 to 70 °C |
| Power | 90 to 250 VAC (47 to 63 Hz) |
| Size (L x W x H) | 10.14" x 5.39" x 6.76" (257 mm x 137 mm x 172 mm) |
| Weight | 8.8 lbs (4 kg) |
