Overview
The TLC 12-fiber distribution cable is designed for high-density indoor networking applications requiring reliable transmission over OM4 multimode fiber. Featuring a 50um core, this cable is optimized for high-speed data communications and is constructed to meet strict plenum fire safety ratings, making it suitable for installation in air-handling spaces.
The cable utilizes 900um tight-buffered fibers, which allow for direct termination without the need for additional breakout kits, significantly reducing installation time and complexity. This distribution-style architecture is ideal for backbone and trunk cabling in data centers, enterprise networks, and campus environments where performance and ease of deployment are critical.
Key Features
-
Tight-Buffered Design
Features 900um buffered fibers for direct connector termination, simplifying the field installation process. -
OM4 Multimode Fiber
Supports high-bandwidth data transmission optimized for short-to-medium distance enterprise network backbones. -
Plenum Rated Jacket
Constructed with a fire-retardant plenum jacket, meeting building code requirements for installation in air-handling plenums. -
12-Fiber Count
Provides sufficient capacity for multiple data streams within a compact, manageable form factor. -
5.8mm Outside Diameter
Small form factor design allows for efficient cable management in congested pathways and conduits. -
Magenta Jacket Color
Industry-standard identification for OM4 fiber, ensuring easy visual distinction from other media types.
Applications
- Data center backbone cabling
- Enterprise network trunking
- Local Area Network (LAN) infrastructure
- High-speed fiber-to-the-desk connections
- Indoor plenum-rated environments
Technical Specifications
| Specification | Value |
|---|---|
| Fiber Type | Multimode (MM) |
| Core Size | 50um |
| Fiber Category | OM4 |
| Fiber Count | 12 |
| Buffer Type | 900um Tight-Buffered |
| Jacket Rating | Plenum |
| Outer Diameter | 5.8mm |
| Jacket Color | Magenta |
Frequently Asked Questions
Does this cable require a breakout kit for termination?
No, the 900um tight-buffered fiber construction allows for direct termination of connectors.
Is this cable suitable for outdoor use?
No, this cable is rated for indoor plenum applications and is not specified for outdoor or direct burial use.
Can this cable be fusion spliced?
Yes, the fibers can easily be fusion spliced to backbone or trunk cables.
What does the 5.8mm OD signify?
It indicates the nominal outside diameter of the cable jacket, which helps in determining conduit fill capacity.
Is the jacket color significant?
Yes, the magenta jacket is the standard color designation for OM4 laser-optimized multimode fiber.
