Overview
This TLC 6-fiber multimode distribution cable is designed for high-density indoor networking environments requiring robust mechanical protection. Featuring 50µm OM3 laser-optimized fiber, this cable supports high-speed data transmission over short to medium distances, making it suitable for backbone cabling in data centers and enterprise LANs.
The construction includes an aluminum interlocking armor (AIA), providing superior crush resistance and protection against physical damage without requiring rigid conduit. The cable is plenum-rated, ensuring it meets strict fire safety requirements for installation in air-handling spaces. Its aqua-colored jacket allows for easy identification as an OM3-rated component.
Key Features
-
6-Fiber Construction
Features six individual strands for high-capacity signal routing in a compact distribution profile. -
50µm OM3 Multimode Fiber
Optimized for 10Gbps data transmission, ensuring reliable performance in modern network architectures. -
Aluminum Interlocking Armor (AIA)
Provides exceptional crush and impact resistance, safeguarding fibers in high-traffic or exposed installations. -
Plenum Rated
Constructed with fire-retardant materials for safe installation in ceiling and floor air-handling plenums. -
12.7mm Outer Diameter
Maintains a manageable cable profile while housing the internal armor and fiber grouping. -
Aqua Jacket
Standard color coding for OM3 fiber, allowing for rapid identification among other network cabling.
Applications
- Data Center backbone cabling
- Enterprise LAN and WAN network links
- Indoor environments requiring rodent or impact protection
- Air-handling plenum spaces
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | TLC |
| Fiber Count | 6 |
| Fiber Type | Multimode 50µm (OM3) |
| Armor Type | Aluminum Interlocking Armor (AIA) |
| Jacket Rating | Plenum |
| Outer Diameter | 12.7mm |
| Jacket Color | Aqua |
Frequently Asked Questions
What is the primary benefit of the aluminum interlocking armor?
The AIA provides a rugged, flexible protective layer that prevents crushing and physical damage to the fibers, often eliminating the need to install the cable inside metal conduit.
Is this cable suitable for outdoor use?
This specific model is designed for indoor applications. Please verify the jacket rating against your specific building code requirements for plenum environments.
Can I use this for 10 Gigabit Ethernet?
Yes, the 50µm OM3 fiber is laser-optimized for high-speed data applications, including 10Gbps Ethernet.
How is this cable sold?
This item is sold by the meter.
What does the aqua jacket indicate?
In standard fiber optic color coding, an aqua jacket identifies the cable as OM3 or OM4 laser-optimized multimode fiber.
