Overview
The Light Connection (TLC) 8-fiber ribbon cable is designed for high-density applications requiring reliable connectivity and simplified installation. This multimode cable features 62.5um fiber construction, protected by aramid yarn and a durable PVC outer jacket, making it suitable for indoor environments requiring a riser (OFNR) fire rating.
This cable is engineered to support standard industry termination methods and is compatible with existing infrastructure components. It provides an efficient solution for environments where space-saving ribbon configurations are necessary for rapid deployment and organized cable management.
Key Features
-
Aramid Strength Member
Integrated aramid yarn provides high tensile strength, protecting the fiber during installation and pulling. -
Multimode 62.5um Fiber
Optimized for short-range communication, ensuring reliable data transmission in enterprise networks. -
Riser (OFNR) Rated
Meets stringent fire safety standards for use in vertical cable runs and building risers. -
Standard Ribbon Configuration
Features an 8-fiber count, facilitating faster mass termination processes compared to simplex cabling. -
RoHS and REACH Compliant
All component materials adhere to international environmental and safety standards. -
TIA Standard Color-Coding
Easily identifiable fiber paths support efficient troubleshooting and connection mapping.
Applications
- High-density data center backbone cabling
- Enterprise LAN/WAN networking
- Vertical building riser installations
- Mass-fusion splicing environments
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | The Light Connection |
| Fiber Count | 8 |
| Fiber Type | Multimode (MM) |
| Core Size | 62.5um |
| Rating | OFNR (Riser) |
| Jacket Material | PVC |
| Strength Member | Aramid Yarn |
Frequently Asked Questions
Is this cable available in other fiber counts?
Yes, while 8-fiber is standard, 2-12 fiber counts are available.
Can I order custom print on the cable jacket?
Yes, custom printing can be accommodated upon request.
Does this cable meet environmental standards?
Yes, all component materials meet the EU RoHS and REACH Directive standards.
What is the jacket rating?
This specific part is UL Listed OFNR (Riser) rated.
Are fan-out kits available for this ribbon cable?
Yes, fan-out kits are available to support termination.
