TLC Distribution Fiber Optic Cable with Aluminum Interlocking Armor, 6 Fiber, Singlemode, Plenum Yellow, 14.15mm OD, Plus Corning® SMF-28® Ultra Fiber, (per meter)
Overview
The TLC Distribution Fiber Optic Cable is designed for indoor applications requiring mechanical protection. This cable features six singlemode fibers utilizing Corning SMF-28 Ultra technology, encased in an aluminum interlocking armor layer for increased crush resistance and durability. The cable is jacketed in a yellow plenum-rated material, suitable for installation in air handling spaces.
Key Features
- Corning SMF-28 Ultra Fiber: Utilizes standardized singlemode glass compatible with existing infrastructure for consistent transmission characteristics.
- Aluminum Interlocking Armor: Provides a robust mechanical barrier to protect fibers against physical impact and crushing during installation or use in high-traffic areas.
- 900um Tight Buffered Fibers: Allows for direct termination of connectors onto the fibers, eliminating the requirement for additional breakout kits.
- Plenum-Rated Jacket: Features a fire-retardant outer sheath that meets safety requirements for installation within environmental air spaces.
- 6-Fiber Construction: Provides six distinct signal pathways within a single cable structure for network cabling density.
Technical Specifications
| Attribute | Specification |
|---|---|
| SKU | S09DI06CZNPYAIA |
| Fiber Count | 6 |
| Fiber Type | Singlemode (Corning SMF-28 Ultra) |
| Cable Type | Distribution |
| Armor Type | Aluminum Interlocking Armor |
| Jacket Rating | Plenum (OFCP) |
| Jacket Color | Yellow |
| Outer Diameter (OD) | 14.15 mm |
| Fiber Construction | 900um Tight Buffered |
| Unit of Measurement | Meter |
