Overview
The TLC Micro-Distribution Cable is a compact, high-density fiber optic solution designed for indoor premises networking. Featuring 2 fibers with 50/125um OM3 laser-optimized multimode glass, this cable utilizes Corning ClearCurve technology to provide superior bend performance and mechanical durability in tight spaces.
Constructed with a plenum-rated jacket, this cable is suitable for installation in air-handling spaces where fire resistance and low smoke emission are required. Its 2mm micro-distribution design facilitates efficient routing in data centers, telecommunications closets, and enterprise network environments.
Key Features
-
OM3 Multimode Fiber
Optimized for 10Gb/s Ethernet transmission over short to medium distances. -
ClearCurve Technology
Engineered with enhanced bend-insensitivity to minimize signal loss during tight routing. -
Plenum-Rated Jacket
Compliant with safety standards for installation in ventilation and air-handling plenums. -
Micro-Distribution Design
Features a small 2mm outer diameter for high-density applications and simplified cable management. -
2-Fiber Configuration
Ideal for point-to-point links and patch cord fabrication. -
Aqua Jacket Color
Industry-standard coloring for easy identification of 50/125um OM3 fiber systems.
Applications
- Data center interconnections
- Building backbone cabling
- Enterprise network premises wiring
- High-density fiber management systems
- Plenum space horizontal cabling
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | TLC |
| Part Number | M50MD02CGNPA20 |
| Fiber Type | Multimode (OM3) |
| Fiber Count | 2 |
| Core/Cladding Size | 50/125um |
| Cable Diameter | 2mm |
| Jacket Rating | Plenum |
| Jacket Color | Aqua |
Frequently Asked Questions
What does the OM3 designation mean?
OM3 refers to laser-optimized 50/125um multimode fiber, which supports 10 Gigabit Ethernet data rates at distances up to 300 meters.
Can this cable be used in ceiling plenums?
Yes, the cable features a plenum-rated jacket, making it suitable for installation in building air-handling spaces.
What is the benefit of ClearCurve technology?
ClearCurve technology makes the fiber significantly more resistant to signal loss caused by tight bends, which is essential for routing in crowded enclosures.
Is this sold by the foot or meter?
This cable is sold by the unit as defined by the ordering increment (per meter).
Does this cable include connectors?
This is a bulk cable product and does not include connectors pre-installed.
