Overview
The TLC Micro-Distribution Cable features a 2-fiber, 50/125um multimode OM4 configuration designed for high-density networking environments. Engineered with bend-insensitive ClearCurve fiber, this cable provides enhanced reliability in tight spaces and complex routing scenarios.
This cable is constructed with a plenum-rated jacket, making it suitable for installation in air-handling spaces (plenums) within data centers and office buildings. The micro-distribution design includes 2mm subunits, facilitating efficient cable management and easier termination during installation.
Key Features
-
ClearCurve Multimode Fiber
Uses bend-insensitive OM4 glass technology to minimize signal loss in tight routing areas. -
Plenum-Rated Jacket
Meets stringent fire safety standards for use in building plenums and air ducts. -
2-Fiber Configuration
Provides a compact, high-performance solution for point-to-point connections. -
2mm Subunits
Designed for efficient space utilization in high-density patching and equipment racks. -
Optimized for OM4
Supports high-speed 10Gbps and 40/100Gbps network applications over longer distances. -
Aqua Jacket Color
Industry-standard coloring for quick identification of OM4 multimode fiber in a rack.
Applications
- Data Center backbone cabling
- Enterprise network distribution
- Plenum-rated indoor routing
- High-density fiber cross-connects
Technical Specifications
| Specification | Value |
|---|---|
| Fiber Count | 2 |
| Fiber Type | Multimode 50/125um (OM4) |
| Cable Type | Micro-Distribution |
| Fiber Technology | ClearCurve |
| Rating | Plenum |
| Subunit Diameter | 2mm |
| Jacket Color | Aqua |
Frequently Asked Questions
What does the Plenum rating mean?
Plenum rating indicates that the cable jacket is constructed from flame-retardant materials, allowing it to be installed in air-handling spaces without the need for conduit.
Is this cable compatible with standard OM4 equipment?
Yes, it is fully compatible with standard 50/125um OM4 transceivers and patch panels.
Why is ClearCurve fiber used?
ClearCurve fiber is bend-insensitive, which significantly reduces the risk of signal attenuation caused by sharp bends or tight installation conditions.
Can this cable be used outdoors?
No, this cable is specifically designed for indoor plenum environments and is not rated for outdoor or buried applications.
What is the benefit of the 2mm subunit?
The 2mm subunits protect individual fibers and simplify the stripping and termination process during installation.
