Overview
The TLC Micro Distribution Fiber Optic Cable is engineered for high-density networking environments requiring a compact, plenum-rated design. Featuring 2 fibers with 2mm sub-units, this cable is optimized for indoor installations in plenums, ducts, and other air-handling spaces where safety and space efficiency are critical.
Equipped with industry-standard Corning SMF-28 Ultra fiber, this cable delivers exceptional optical performance and bend-insensitive characteristics. Its robust construction ensures easy routing and termination, making it an ideal choice for data centers, enterprise backbones, and telecommunication distribution systems.
Key Features
-
Corning SMF-28 Ultra Fiber
Provides low-loss performance and improved macrobend resistance for reliable long-term connectivity. -
Plenum Rated Jacket
Ensures compliance with stringent fire safety regulations for installation in air-handling spaces. -
Micro Distribution Construction
Compact design maximizes conduit utilization and simplifies cable management in high-density racks. -
2mm Sub-units
Individual fiber protection allows for direct termination and simplified cable identification. -
2-Fiber Configuration
Supports basic singlemode links with a versatile yellow jacket for industry-standard identification. -
Optimized for Indoor Use
Engineered for reliable operation in climate-controlled environments and enterprise network infrastructures.
Applications
- Data center inter-cabinet connectivity
- Enterprise backbone installations
- Plenum spaces and air-handling ducts
- Telecommunications distribution systems
- Horizontal and vertical cable runs
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | TLC |
| Fiber Type | Singlemode (Corning SMF-28 Ultra) |
| Fiber Count | 2 |
| Sub-unit Size | 2mm |
| Jacket Rating | Plenum |
| Jacket Color | Yellow |
| Part Number | S09MD02CZNPY20 |
Frequently Asked Questions
What does the plenum rating signify?
The plenum rating indicates that the cable jacket meets specific fire safety standards, allowing it to be installed in HVAC air-handling spaces without the need for metal conduit.
Can this cable be used outdoors?
This cable is specifically rated for indoor plenum applications and is not designed for direct burial or outdoor environmental exposure.
What is the benefit of Corning SMF-28 Ultra fiber?
It offers superior bend insensitivity compared to standard singlemode fiber, which reduces signal loss in tight routing environments.
Is the cable sold by the meter?
Yes, this product is sold by the meter to accommodate specific project requirements.
Does this cable support 2mm connectors?
Yes, the 2mm sub-units are compatible with industry-standard 2mm fiber optic connectors.
