Overview
This TLC Micro Distribution Fiber Optic Cable is designed for indoor data center and enterprise network environments where space-saving high-density cabling and robust physical protection are required. Engineered with a plenum-rated jacket and aluminum interlocking armor, this cable provides superior crush resistance and flame retardancy, making it suitable for installation in air-handling spaces without the need for additional conduit.
Featuring 24 strands of Corning® SMF-28® Ultra fiber, this cable delivers exceptional optical performance, including low attenuation and industry-leading macrobending tolerance. The micro-distribution construction allows for a compact outer diameter compared to traditional distribution cables, significantly simplifying cable routing in crowded racks and trays while ensuring long-term network reliability.
Key Features
-
Aluminum Interlocking Armor
Provides high mechanical protection against crush and impact forces, eliminating the need for conduit during installation. -
24-Fiber Construction
High fiber density enables efficient use of space in trays and conduits for backbone cabling. -
Plenum Rated (OFCP)
Ensures compliance with strict fire safety codes for use in air-handling plenums and raised floor systems. -
Corning® SMF-28® Ultra Fiber
Offers world-class optical performance with improved macrobend resistance and compatibility with legacy networks. -
Compact Micro-Distribution Design
Smaller outer diameter facilitates easier handling, installation, and cable management in high-density environments. -
Singlemode Fiber
Optimized for high-bandwidth, long-distance transmission across enterprise and campus backbones.
Applications
- Data center backbone cabling
- Enterprise network inter-building runs
- Air-handling plenum spaces
- High-density fiber distribution
- Cable runs requiring high physical protection
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | TLC |
| Fiber Type | Singlemode (Corning® SMF-28® Ultra) |
| Fiber Count | 24 |
| Rating | Plenum (OFCP) |
| Armor | Aluminum Interlocking |
| Color | Yellow |
Frequently Asked Questions
What does the plenum rating mean for this cable?
Plenum rating indicates that the cable jacket is constructed with materials that meet high fire safety standards for low smoke and flame spread, allowing it to be installed in environmental air-handling spaces.
Can this cable be used outdoors?
This cable is designed specifically for indoor use with a plenum-rated jacket. For outdoor environments, moisture-resistant and UV-protected cable types are typically required.
What is the benefit of aluminum interlocking armor?
The armor provides a rugged metallic layer that protects the internal fiber strands from crushing and accidental cuts, which is ideal for areas where the cable might be subjected to heavy foot traffic or equipment weight.
Is this compatible with standard singlemode connectors?
Yes, it utilizes industry-standard Corning® SMF-28® Ultra fiber, which is fully compatible with all standard singlemode termination processes and equipment.
Why is the fiber count important?
The 24-fiber count allows for high-capacity signal routing through a single cable, reducing the number of individual cables that need to be managed in your pathways.
