VERSA Splitter Module 1x32 with 1.6mm Tails - LC/APC

Overview

The VERSA Splitter Module is a 1x32 Planar Lightwave Circuit (PLC) splitter designed for high-density fiber management environments. Engineered for reliability in split-ratio applications, this module features a durable ABS box construction with integrated bulkhead adapters for efficient connectivity.

This unit comes equipped with 1.6mm cable tails, utilizing color-coded inputs (red) and outputs (black) to streamline identification and routing during installation. With a lead length of 25 meters, it is suited for various distribution architectures in telecommunications and enterprise networking.

Key Features

• 1x32 Split Ratio
  Standardized splitting for efficient signal distribution in PON networks.
• PLC Technology
  Planar Lightwave Circuit technology provides stable optical performance across a wide wavelength range.
• ABS Modular Design
  Compact housing enables space-saving installation in fiber distribution hubs.
• LC/APC Connectivity
  Angled Physical Contact connectors minimize back-reflection for enhanced signal integrity.
• Color-Coded Cabling
  Input and output tails are clearly distinguished, reducing the risk of installation errors.
• 1.6mm Jacket
  Small-diameter cabling allows for easier cable management within enclosures.

Technical Specifications

Frequently Asked Questions

What is the maximum insertion loss for this splitter?
The maximum insertion loss is ≤16.8dB, which includes the loss from a pair of connectors.

Does this module come with connectors pre-installed?
Yes, it features LC/APC connectors on the tails.

What environment is this splitter intended for?
It is designed for temperatures ranging from -40°C to +85°C, making it suitable for varied installation conditions.

Downloads

• Product PDF
