VIAVI FBPT-SC-APC SC/APC Bulkhead Tip for FBP Probe Microscopes

Overview

The VIAVI FBPT-SC-APC is a precision-engineered bulkhead inspection tip designed specifically for use with the FBP series probe microscopes. This accessory enables technicians to perform high-resolution visual inspections of fiber optic connector end-faces residing within SC/APC bulkhead adapters.

Engineered for consistent optical alignment, this inspection tip ensures accurate analysis of connector cleanliness and surface integrity. Its robust construction is suitable for demanding field environments, data centers, and telecommunications installations where verifying signal quality through proper end-face hygiene is critical for network performance.

Key Features

• Optimized Connector Geometry
  Specifically designed for SC/APC bulkhead connectors to ensure precise centering and focus during inspection.
• High-Resolution Compatibility
  Engineered to work seamlessly with VIAVI FBP series digital probe microscopes for clear, accurate end-face imaging.
• Durable Construction
  Built to withstand frequent insertion and removal cycles in standard field and data center conditions.
• Simplified Attachment
  Features a quick-connect interface allowing for rapid switching of tips during multi-connector testing sequences.
• APC Interface Support
  Specifically shaped to accommodate the angled physical contact (APC) requirements of single-mode SC connectors.
• Consistent Inspection Quality
  Ensures repeatable inspection results, essential for adhering to IEC 61300-3-35 fiber cleanliness standards.

Applications

• Fiber optic network maintenance and troubleshooting
• Data center cabling infrastructure inspection
• Telecommunications field service
• Quality assurance of fiber end-face terminations

Technical Specifications

Frequently Asked Questions

Is this tip compatible with non-VIAVI microscopes?
This tip is designed specifically for the VIAVI FBP series probe microscopes and is not guaranteed to be compatible with other inspection systems.

Does this support PC (Physical Contact) connectors?
No, this tip is specifically for APC (Angled Physical Contact) connectors. Using it on flat PC connectors may result in improper alignment or inaccurate images.

How do I clean the inspection tip?
Follow the cleaning instructions provided in your FBP probe manual, typically using lint-free fiber cleaning swabs or air duster to avoid damaging the internal optics.

Can I use this for patch cord inspection?
This tip is intended for bulkhead adapters. For patch cord (male) connectors, a different adapter tip is usually required.

What is the primary function of this tip?
It allows the probe microscope to align perfectly with an SC/APC connector seated inside a bulkhead adapter for visual inspection.
